Hydraulic T Bolt Clamp

Name: Hydraulic T Bolt Clamp
Brand: OMSON HYDRO SOLUTIONS
Price: 14500 INR
Availability: InStock

Price 14500 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Hydraulic T Bolt Clamp Specification

Tensile Strength
High (Up to 800 MPa)

Density
7.8 Gram per cubic centimeter(g/cm3)

Material Grade
A2 / A4

Weight
Variable (Depends on Size)

Metal Type
Stainless Steel

Material
Stainless Steel 304 / 316

Structure
T-Bolt

Standard
DIN 3017

Shape
Round

Hydraulic T Bolt Clamp Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Telegraphic Transfer (T/T), Cheque

Supply Ability
100 Units Per Month

Delivery Time
3-4 Days

Packaging Details
Boxes

Main Export Market(s)
Australia, North America, Eastern Europe, Western Europe, Middle East, Africa, Central America, South America, Asia

Main Domestic Market
All India

About Hydraulic T Bolt Clamp

A safe, quick and simple way to clamp dies, work pieces, and fixtures
Positive clamping & remained clamped in case of leakage in hose or bursting of Hose Pipe.
Easily inserted into existing T-slots. Clamps at any position along the length of the T-bolt
Hydraulically operated. Available with or without mechanical lock-collet
Self locking in clamped position with the mechanical lock-collet option
Can be used with existing or specially hardened T-bolts

High-Performance Clamping for Hydraulic Applications

Engineered to secure hydraulic hoses, this T Bolt Clamp features a round, flat-end structure and is crafted from A2/A4 grade stainless steel for uncompromising durability. Its adjustable bolt tightening system assures steadfast performance, accommodating a wide range of hose diameters while maintaining high tensile strength and corrosion resistance. Suitable for intensive industrial and hydraulic system environments.

Outstanding Corrosion Resistance and Temperature Tolerance

Finished with either zinc plating or mirror polishing, this clamp thrives in harsh, corrosive conditions and across a significant temperature spectrum, from -40C to +250C. The premium materials and finishes make it highly suitable for both indoor and outdoor applications, ensuring long operational life and dependability even under severe load or environmental stress.

FAQs of Hydraulic T Bolt Clamp:

Q: How does the adjustable bolt tightening mechanism benefit hose installations?

A: The adjustable bolt tightening mechanism allows precise tension control, ensuring a secure and leak-proof fit on hydraulic hoses of various sizes within the 38 mm to 168 mm range. This adaptability minimizes installation issues, enhances safety, and prevents hose slippage during operation.

Q: What applications are ideal for using the Hydraulic T Bolt Clamp?

A: This clamp is particularly well-suited for hydraulic systems, hose fittings, industrial machinery, and environments where a robust solution is needed for securing hoses exposed to high pressure, temperature fluctuations, and corrosive conditions.

Q: When should stainless steel 304 or 316 be chosen for the clamp material?

A: Stainless steel 304 provides strong corrosion resistance for general environments, while 316 is preferred for highly corrosive or marine settings due to its superior resistance to chemical exposure. The choice depends on the specific environmental demands of your application.

Q: Where can I source these Hydraulic T Bolt Clamps in India?

A: These clamps are supplied by dealers, distributors, exporters, manufacturers, service providers, suppliers, and wholesalers across India, with support for various industries and custom requirements. They can be ordered directly for both small and large-scale projects.

Q: What is the process for installing a Hydraulic T Bolt Clamp?

A: Installation involves positioning the clamp around the hose and fitting, aligning it properly, and using the hex nut to adjust and tighten the T-bolt, creating a reliable and uniform clamping force. The adjustable design allows easy adjustment and maintenance.

Q: How does the clamps high corrosion resistance enhance its service life?

A: Thanks to its zinc plated or mirror polished finish and use of stainless steel 304/316, the clamp effectively resists rust and corrosion, even in wet or chemically aggressive environments. This extends service life and maintains reliability over prolonged use.

Q: What distinguishes this clamp in terms of strength and reliability?

A: The clamps structure and material, offering up to 800 MPa tensile strength, ensure it withstands high pressures common in hydraulic systems. The flat end and round shape provide a balanced, secure grip, reducing the risk of hose damage or leakage.
